ZFS with Redhat Cluster Suite

Friday, July 25th, 2014

This is a very nice project I have been working on. The hardware at hand – two servers, with a shared SAS bus containing several SAS disks. Since it’s a shared bus, no RAID solution would cut it, and as I don’t want to waste disks with ASM (“normal” redundancy meaning half the size…), I went to ZFS storage.

ZFS is a wonderful technology, with many advantages, but with some dangerous pitfalls. As I prefer Linux, I did not bother with any Sloaris solutions, and went directly to Centos 6. I will describe my cluster setup below.

I will disclose the entire setup, including hardware layout, Linux platform, ZFS module parameters, the Redhat Cluster Suite ZFS agent I wrote and the cluster.conf configuration file. I will also share my considerations regarding some of the choices I made. In addition, this system was designed to act as NFS storage for Citrix XenServer pool, so I will have to describe the changed I had to perform on the XenServer itself (which might make it unsupported, but I will have to live with it), to allow it to handle the timeouts resulting by server failover.

So first – the servers – each having a single CPU (quad core), 24GB RAM, and dual 1Gb/s NICs. Also – a tiny internal SATA disk is used for the OS. The shared disks – at the moment, 10 SAS disks, dual port (notice – older HP disks might mark in a very small letters that they are only a single-port SAS disks…), 72GB, 10K RPM. Zpool called ‘share’ with two 5 disks RaidZ1 vdevs. As I mentioned before – ZFS seemed like the best possible option allowing me to achieve my goals at minimal cost.

When I came to this project, I wanted to be able to use a native ZFS cluster agent, and not a ‘script’ agent, which takes a very long time to respond (30 seconds). Also – I wanted to be able to handle multiple storage pools concurrently – each floating on its own. While I have only one at the moment, I wanted the ability to have a fine-grained control over multiple pools. In addition – I am unable (or unwilling?) to handle the multiple filesystems introduced with each pool. I wanted to be able to import or export the pool silently, and with a clear head, thus I had to verify that the multiple filesystems are not in use as part of the export process.

As an agent, I wanted to comply with Redhat Cluster Suite (RHCS from now on) OCF syntax. I used the supplied fs.sh script as an inspiration for my agent script, so some of it might look familiar. All credit goes to the original authors, of course.

The operating system I selected was Centos 6. Centos is based on Redhat Linux, and I find it mature and stable, which is exactly what I want when I plan a production-ready, enterprise-class storage solution. The version had to be x86_64, due to ZFS requirements, and due to the amount of RAM in the server.

To handle ZFS options, I added a file called /etc/modprobe.d/zfs.conf, with the following content

install zfs /bin/rm -f /etc/zfs/zpool.cache && /sbin/modprobe –ignore-install zfs
options zfs zfs_arc_max=12593790976
options zfs zfs_arc_min=12593790975

I had to verify there is no zpool.cache file. Since my pool was rather small (planned for 24 disks max), I was not concerned by the longer import process caused by not having the zpool.cache file. I was more concerned with automatic import process which might happen, and had to prevent it at almost any cost. In addition, I learned from other systems that the arc memory should never exceed half the RAM, and it should be given just a little under that.

Of course, when changing such module settings, you need to recreate initrd (dracut -f) to be on the safe side later on.

The zfs.sh agent script was placed in /usr/share/cluster directory. You must have rgmanager installed for this directory to exist, and anyhow, without rgmanager, you will have no cluster whatsoever.

This is the contents of the zfs.sh file. Notice that it is not compatible with Luci, so if you’re using it – them kids won’t play well together.

#!/bin/bash

LC_ALL=C
LANG=C
PATH=/bin:/sbin:/usr/bin:/usr/sbin
export LC_ALL LANG PATH
# Private return codes
FAIL=2
NO=1
YES=0
YES_STR="yes"

. $(dirname $0)/ocf-shellfuncs

meta_data()
{
    cat <

    1.0

	This script will import and export ZFS storage pools
	It will make sure to mount and umount all child filesystems

        This is a ZFS pool

                Symbolic name for this zfs pool

                File System Name

		ZFS Pool name or ID

                ZFS pool name

		ZFS Pool alternate mount

                ZFS pool alternate mount

                If set, the cluster will kill all processes using
                this file system when the resource group is
                stopped.  Otherwise, the unmount will fail, and
                the resource group will be restarted.

                Force Unmount

                If set and unmounting the file system fails, the node will
                immediately reboot.  Generally, this is used in conjunction
                with force-unmount support, but it is not required.

                Seppuku Unmount

	<!-- Note: active monitoring is constant and supplants all              check depths -->
        <!-- Checks to see if we can read from the mountpoint -->

        <!-- Checks to see if we can write to the mountpoint (if !ROFS) -->

EOT
}

ocf_log()
{
        echo $*
}

verify_driver() {
	ocf_log info "Verifying ZFS driver"
	lsmod | grep -w zfs &gt; /dev/null 2&gt;&amp;1 &amp;&amp; return 0
	ocf_log err "ZFS driver is not loaded"
	return $OCF_ERR_ARGS
}

verify_poolname() {
	ocf_log info "Verify pool name "
	if [ -z "$OCF_RESKEY_pool" ]
	then
		ocf_log err "Missing pool name"
		return $OCF_ERR_ARGS
	fi
	zpool import | grep pool: | grep -w $OCF_RESKEY_pool &gt; /dev/null 2&gt;&amp;1 &amp;&amp; return 0
	ocf_log err "Cannot identify pool name"
	return $OCF_ERR_ARGS
}

verify_mounted_poolname() {
	ocf_log info "Verify pool name "
	if [ -z "$OCF_RESKEY_pool" ]
	then
		ocf_log err "Missing pool name"
		return $OCF_ERR_ARGS
	fi
	zpool list $OCF_RESKEY_pool &gt; /dev/null 2&gt;&amp;1 &amp;&amp; return 0
	ocf_log err "Cannot identify pool name"
	return $OCF_ERR_ARGS
}

verify_mountpath() {
	ocf_log info "Verifying alternate root mount path"
	[ -z "$OCF_RESKEY_mount" ] &amp;&amp; return 0
	declare mp="${OCF_RESKEY_mount}"
	case "$mp" in
		/*)    	# found it
                	;;
        	*)      # invalid format
			ocf_log err \
"verify_mountpath: Invalid mount point format (must begin with a '/'): \'$mp\'"
                return $OCF_ERR_ARGS
                ;;
        esac
}

pool_import() {
	ocf_log info "Importing pool"
	OPTS=""
	[ -n "$OCF_RESKEY_mount" ] &amp;&amp; OPTS="-R $OCF_RESKEY_mount"
	zpool import $OCF_RESKEY_pool $OPTS
	RET="$?"
	if [ "$RET" -ne "0" ]
	then
		ocf_log info "Cannot import without applying force"
		zpool import -f $OCF_RESKEY_pool $OPTS
		RET="$?"
	fi
	if [ "$RET" -ne "0" ]
	then
		ocf_log err "Pool import failed for $OCF_RESKEY_pool. error=$RET"
		return 1
	fi
	ocf_log info "Imported ZFS pool"
	return $RET
}

check_and_release_fs() {
	ocf_log info "Checking and releasing FS"
	FS=""
	case ${OCF_RESKEY_force_unmount} in
        $YES_STR|on|true|1)	force_umount=$YES ;;
        *)		        force_umount="" ;;
        esac

	RET=0
	for i in `zfs list -t filesystem | grep ^${OCF_RESKEY_pool} | awk '{print $NF}'`
	do
		# To be on the safe side. Why not?
		sleep 1
		# Is it mounted?
		if ! df -l | grep -w "$i" &gt; /dev/null 2&gt;&amp;1
		then
			ocf_log info "Filesystem $i is not mounted"
			continue
		fi
		if [ `lsof $i | wc -l` -gt "0" ]
		then
			ocf_log info "Filesystem $i is in use"
			if [ "$force_umount" ]
			then
				ocf_log info "Attempting to kill processes on $i filesystem"
				fuser -k $i
				sleep 2
				if [ `lsof $i | wc -l` -gt "0" ]
				then
					ocf_log err "Cannot umount filesystem $i - filesystem in use"
					return 1
				fi
			else
				ocf_log err "Cannot umount filesystem $i
 - filesystem in use"
                                return 1
			fi
		fi
	done
	return $RET
}

self_fence() {
	ocf_log info "Should we validate and call self-fence?"
	case ${OCF_RESKEY_self_fence} in
		$YES_STR|on|true|1)       self_fence=$YES ;;
       		*)              self_fence="" ;;
        esac

	if [ "$self_fence" ]; then
		ocf_log alert "umount failed - REBOOTING"
               	sync
                reboot -fn
	fi
	return $OCF_ERR_GENERIC
}

pool_export() {
	ocf_log info "Exporting zfs pool"
	check_and_release_fs || self_fence
	zpool export $OCF_RESKEY_pool
	RET="$?"
	if [ "$RET" -ne "0" ]
	then
		ocf_log err "Pool export failed for $OCF_RESKEY_pool. error=$RET"
		return 1
	fi
	return $RET
}

start() {
	ocf_log info "Starting ZFS"
	verify_driver || return $OCF_ERR_ARGS
	verify_poolname || return $OCF_ERR_ARGS
	verify_mountpath || return $OCF_ERR_ARGS
	pool_import
	# Handle filesystem?
}

stop() {
	ocf_log info "Starting ZFS"
	verify_driver || return $OCF_ERR_ARGS
	verify_mounted_poolname || return $OCF_ERR_ARGS
	verify_mountpath || return $OCF_ERR_ARGS
	# Handle filesystem?
	pool_export
}

is_imported() {
	ocf_log debug "Checking if $OCF_RESKEY_pool is imported"
	zpool list ${OCF_RESKEY_pool} &gt; /dev/null 2&gt;&amp;1
	return $?
}

is_alive() {
	ocf_log debug "Checking ZFS pool read/write"
	declare file=".writable_test.$(hostname)"
	declare TIMEOUT="10s"
	[ -z "$OCF_CHECK_LEVEL" ] &amp;&amp; export OCF_CHECK_LEVEL=0
	mount_point=`zfs list ${OCF_RESKEY_pool} | grep ${OCF_RESKEY_pool} | awk '{print $NF}'`
	test -d "$mount_point"
        if [ $? -ne 0 ]; then
                ocf_log err "${OCF_RESOURCE_INSTANCE}: is_alive: $mount_point is not a directory"
                return $FAIL
        fi
	[ $OCF_CHECK_LEVEL -lt 10 ] &amp;&amp; return $YES

        # depth 10 test (read test)
        timeout -s 9 $TIMEOUT ls "$mount_point" &gt; /dev/null 2&gt; /dev/null
        errcode=$?
        if [ $errcode -ne 0 ]; then
                ocf_log err "${OCF_RESOURCE_INSTANCE}: is_alive: failed read test on [$mount_point]. Return code: $errcode"
                return $NO
        fi

	[ $OCF_CHECK_LEVEL -lt 20 ] &amp;&amp; return $YES

        # depth 20 check (write test)
        rw=$YES
        for o in `echo $OCF_RESKEY_options | sed -e s/,/\ /g`; do
                if [ "$o" = "ro" ]; then
                        rw=$NO
                fi
        done
	if [ $rw -eq $YES ]; then
                file="$mount_point"/$file
                while true; do
                        if [ -e "$file" ]; then
                                file=${file}_tmp
                                continue
                        else
                                break
                        fi
                done
                timeout -s 9 $TIMEOUT touch $file &gt; /dev/null 2&gt; /dev/null
                errcode=$?
                if [ $errcode -ne 0 ]; then
                        ocf_log err "${OCF_RESOURCE_INSTANCE}: is_alive: failed write test on [$mount_point]. Return code: $errcode"
                        return $NO
                fi
                rm -f $file &gt; /dev/null 2&gt; /dev/null
        fi

	return $YES
}

monitor() {
	ocf_log debug "Checking ZFS pool $OCF_RESKEY_pool, Level $OCF_CHECK_LEVEL"
	verify_driver || return $OCF_ERR_ARGS
	is_imported
	RET=$?
	if [ "$RET" -ne $YES ]; then
                ocf_log err "${OCF_RESOURCE_INSTANCE}: ${OCF_RESKEY_device} is not mounted on ${OCF_RESKEY_mountpoint}"
                return $OCF_NOT_RUNNING
        fi
	is_alive
	return $RET
}

if [ -z "$OCF_CHECK_LEVEL" ]; then
	OCF_CHECK_LEVEL=0
fi

case $1 in
start)
	ocf_log info "zfs start $OCF_RESKEY_pool\n"
	OCF_CHECK_LEVEL=0
	monitor
	[ "$?" -ne "0" ] &amp;&amp; start || ocf_log info "$OCF_RESKEY_pool is already mounted"
	exit $?
	;;
stop)
	ocf_log info "zfs stop $OCF_RESKEY_pool\n"
	OCF_CHECK_LEVEL=0
	monitor
	[ "$?" -eq "0" ] &amp;&amp; stop || ocf_log info "$OCF_RESKEY_pool is not mounted"
	exit $?
	;;
status|monitor)
	ocf_log debug "ZFS monitor $OCF_RESKEY_pool"
	monitor
	exit $?
	;;
meta-data)
	echo -e "zfs metadat $OCF_RESKEY_address\n" &gt;&gt;/tmp/out
	meta_data
	exit 0
	;;
validate-all)
	exit 0
	;;
*)
	echo "usage: $0 {start|stop|status|monitor|restart|meta-data|validate-all}"
	exit $OCF_ERR_UNIMPLEMENTED
	;;
esac

All I had to do now was to build the cluster.conf file.

The reason I placed the IP address as the last to start and the first to stop was that the other way around, the NFS client would receive an ordered disconnection command, and would not bother to establish a connection with the remaining server. Abruptly taking away the clustered IP address causes the NFS clients to initiate a reconnection process, of which the systems are supposed to recover

I have left this article incomplete for a while now. It has some stuff I do like to share, so I am sharing it as-is. I will (some day) complete it.

Two advanced bash tricks

Saturday, June 7th, 2014

Well, tricks is not the right word to describe advanced shell scripting usage, however, it does make some sense. These two topics are relevant to Bash version 4.0 and above, which is common for all modern-enough Linux distributions. Yours probably.

These ‘tricks’ are for advanced Bash scripting, and will assume you know how to handle the other advanced Bash topics. I will not instruct the basics here.

Trick #1 – redirected variable

What it means is the following.

Let’s assume that I have a list of objects, say: ‘LIST=”a b c d”‘, and you want to create a set of new variables by these names, holding data. For example:

a=1
b=abc
c=3
d=$a

How can you iterate through the contents of $LIST, and do it right? If you’re having only four objects, you can live with stating them manually, however, for a dynamic list (example: the results of /dev/sd*1 in your system), you might find it a bit problematic.

A solution is to use redirected variables. Up until recently, the method involved a very complex ‘expr’ command which was unpleasant at best, and hard to figure at its worst. Now we can use normal redirected variables, using the exclamation mark. See here:

for OBJECT in $LIST
do
# Place data into the list
export $OBJECT=$RANDOM
done

for OBJECT in $LIST
do
# Read it!
echo ${!OBJECT}
done

Firstly – to assign value to the redirected variable, we must use ‘export’ prefix. $OBJECT=$RANDOM will not work.
Secondly – to show the content, we need to use exclamation mark inside the variable curly brackets, meaning we cannot call it $!OBJECT, but ${!OBJECT}.
We cannot dynamically create the variable name inside the curly brackets either, so ${!abc_$SUFFIX} won’t work either. We can create the name beforehand, and then use it, like this: DynName=abc_$SUFFIX ; echo ${!DynName}

Trick #2 – Using strings as an array index

It was impossible in the past, but now, one of the most useful features of having smart list is accessible in shell. We can now call an array with a label. For example:

for FILE in $( ls )
do
array["$FILE"]=$( ls -la $FILE | awk ‘{print $7}’ )
done

In this example we create array cells with the label being the name of the file, and populating them with the size (this is the result of ls -la 7th field) of this file.

This will work only if the array was declared beforehand using the following command (using the array name ‘array’ here):

declare -A array

Later on, it is easier to query data out of the array, as long as you know its index name. For example

FILE=ez-aton.txt
echo ${array[$FILE]}

Of course – assuming there is an entry for ez-aton.txt in this array.

The best use I found for this feature so far was for comparing large lists, without the need to reorder the objects in the array. I find it to boost the capabilities of arrays in Bash, and arrays, in general, are very powerful tools to handle long and complex lists, when you need to note the position.

That’s all fox. Note that the blog editor might change quites (single and double) and dashes to the UTF-8 versions, which will not go well in a copy/paste attempt to experiment with the code examples placed here. You might need to edit the contents and fix the quotes/dashes manually.

If you have any questions, comment here, I will be happy to elaborate. I hope to be able to add more complex Bash stuff I get into once a while :-)

BackupExec 2012 (14) on newer Linux

Tuesday, August 6th, 2013

In particular – Oracle UEK, which “claims” to be 2.6.39-xxx, but is actually 3.0.x with a lower version number. Several misbehaviors (or differences) of version 3 can be found. One of them is related to BackupExec. The service would not start on OEL6 with UEK kernels. The cause of it is an incorrect use of a function – getIfAddrs. Everything can be seen in this amazing post. The described patch works, at least to allow the service to start. Check out the comments for some insights about how to identify the correct call.

I am re-posting it here, so it can be found for Oracle Universal Enterprise Kernel (UEK) as well.

Cacti NetApp Ontap API data query

Sunday, June 23rd, 2013

I have been using the excellent template and scripts from this forum post, however, when the NetApp device is loaded with LUNs and volumes, the script will cause the Cacti to timeout, and during that time, consume CPU. The original cause of this problem was a workaround to some NetApp Perl API bug the original author found, which forced him to query the entire data set for each sub-query. This is nice for five, or even ten volumes, but when you’re around 400 volumes, things just look bad.

Due to that, I have taken upon myself to make this script more scalable, but forcing a single data query from the NetApp for each data type (volume, LUN, system, etc) and data query type (get, index, etc). A unique file was created with its name being the storage_device_name.data_type.query_type. Following queries to any subset of this data were just accessing this file, and not the remote NetApp device, killing network, CPU, and tending to time out on operation and leave huge blank parts in the graphs.

I will post my modified template in the forum as well, but I place it here, just so that it will be both available for me, and for any interested reader.

Get it here: NetApp_OnTap-SDK_cacti-20130623.tar.gz



XenServer – Setting virtual disks names based on the VM names

Wednesday, January 2nd, 2013

One of the worst things you can have in XenServer, is some wize-guy performing a ‘forget storage’ on a storage device still holding virtual disks related to VMs. As XenServer database is internal (for the whole pool) and not per-VM, all references to this virtual disks disappear, and you remain with bunch of VMs without disks, and later on, when the recovered from the shock and restored the SR, with a bunch of virtual disks you have no clue as to where they belong. Why? Because we are lazy, and we tend to skip the part where you can (or is it – should?) define a custom name for your virtual disks so you would know later on (for example – in the case specified above) where they belong(ed).

To solve this annoying issue, and to save time for Citrix XenServer admins, I have created a script which resets the VDI (virtual disk object) names to the name of the VM+ the logical position of the virtual disk (example: xvda, hdb, etc), related to the VM. That way, it will become very easy to identify the disks in case of such annoying micro-catastrophy (micro because no data is lost, just where it belongs…).

The script can be called manually, and since we’re lazy people, and we will forget to handle it manually every said interval, and will accumulate virtual machines with “Template of XYZ” virtual disks, it can be called from cron. When called manually, it asks the user to proceed by pressing ‘Enter’. If called from cron, it just runs.

Enjoy!



1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
#!/bin/bash
# This script will reset the names of the virtual disks used for each VM to a standard name, based on the VM name
# and the disk position
# It is meant to solve problems where due to 'forget storage' operations or the likes
# virtual disk associations disappear, and you face many disks having the same name
#
# Written by Ez-Aton: http://run.tournament.org.il


if [ -t 1 ]
then
        echo "This script will reset *all* VM disks to a name constructed of the VM and the disk name (xvda, hdb, etc)"
        echo "This operation is not reversible, however, it can be called repeatedly"
        echo "If you want this script to skip a said virtual disk, make sure its name includes the name of the VM"
        echo "For example 'vm1 the real important data disk' for a disk used by vm1."
        echo "Note that the name is case sensitive, and it is very important that to match the name using upper/lower case letters as needed"
        echo "To abort, press Ctrl+C"
        echo "To proceed, press Enter"
        read abc
fi

VM_LIST=`xe vm-list is-control-domain=false --minimal | tr , ' '`

for i in $VM_LIST
do
        # Resetting several parameters, so we have a clean start
        VM_NAME=""
        VBD_LIST=""
        VDI_LIST=""
        # We iterate through all existing VMs, to get both their names, and their disks
        VM_NAME="`xe vm-param-get uuid=$i param-name=name-label`"
        if [ -z "$VM_NAME" ]
        then
                # We have a problem with empty VM names, so we will use the VMs uuid
                VM_NAME=$i
        fi
        VBD_LIST=`xe vbd-list vm-uuid=$i --minimal | tr , ' '`
        for j in $VBD_LIST
        do
                # Resetting several parameters, so we have a clean start
                VDI_UUID=""
                DEV_NAME=""
                # We iterate through all existing VBDs to reset the VDI nane
                VDI_UUID=`xe vbd-param-get uuid=$j param-name=vdi-uuid`
                if [ "$VDI_UUID" == "<not in database>" ]
                then
                        # This is a virtual CDROM
                        continue
                fi
                DEV_NAME=`xe vbd-param-get uuid=$j param-name=device`
                VDI_NAME=`xe vbd-param-get uuid=$j param-name=vdi-name-label`

                # Test if the name was reset in the past or manually
                TGT_NAME="$VM_NAME $DEV_NAME"
                if [[ "$TGT_NAME" = "$VDI_NAME" ]]
                then
                        # There is nothing to do
                        echo "Name already includes VM name, so nothing to do"
                else
                        # Here we reset the VDI name
                        echo xe vdi-param-set uuid=$VDI_UUID name-label="$TGT_NAME"
                        xe vdi-param-set uuid=$VDI_UUID name-label="$TGT_NAME"
                fi
        done
done

XenServer get VM by MAC

Wednesday, December 5th, 2012

Using the GUI, it could be somewhat complex identifying a VM based on its MAC address. There are several solutions on the network using PowerShell, but I will demonstrate it using a simple bash script, below. Save, make executable, and run.

Enjoy



1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
#!/bin/bash
if [ -z "$1" ]
then
	echo "Requires parameter - MAC address"
	exit 1
fi

MAC=$1
# You might want to check MAC correctness here. Enjoy doing it. RegExp, man!

# XenServer is agnostic to case for MAC addresses, so we don't care
VIF_UUID=`xe vif-list MAC=$MAC | grep ^uuid | awk '{print $NF}'`

VM=`xe vif-param-list uuid=$VIF_UUID | grep vm-name-label | awk '{print $NF}'`

echo "MAC $MAC has VM $VM"

Attach USB disks to XenServer VM Guest

Saturday, May 5th, 2012

There is a very nice script for Windows dealing with attaching XenServer USB disk to a guest. It can be found here.

This script has several problems, as I see it. The first – this is a Windows batch script, which is a very limited language, and it can handle only a single VDI disk in the SR group called “Removable Storage”.

As I am a *nix guy, and can hardly handle Windows batch scripts, I have rewritten this script to run from Linux CLI (focused on running from the XenServer Domain0), and allowed it to handle multiple USB disks. My assumption is that running this script will map/unmap *all* local USB disks to the VM.

Following downloading this script, you should make sure it is executable, and run it with the arguments “attach” or “detach”, per your needs.

And here it is:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
#!/bin/bash
# This script will map USB devices to a specific VM
# Written by Ez-Aton, http://run.tournament.org.il , with the concepts
# taken from http://jamesscanlonitkb.wordpress.com/2012/03/11/xenserver-mount-usb-from-host/
# and http://support.citrix.com/article/CTX118198

# Variables
# Need to change them to match your own!
REMOVABLE_SR_UUID=d03f247d-6fc6-a396-e62b-a4e702aabcf0
VM_UUID=b69e9788-8cd2-0074-5bc1-63cf7870fa0d
DEVICE_NAMES="hdc hde" # Local disk mapping for the VM
XE=/opt/xensource/bin/xe

function attach() {
        # Here we attach the disks
        # Check if storage is attached to VBD
        VBDS=`$XE vdi-list sr-uuid=${REMOVABLE_SR_UUID} params=vbd-uuids --minimal | tr , ' '`
        if [ `echo $VBDS | wc -w` -ne 0 ]
        then
                echo "Disks are allready attached. Check VBD $VBDS for details"
                exit 1
        fi
        # Get devices!
        VDIS=`$XE vdi-list sr-uuid=${REMOVABLE_SR_UUID} --minimal | tr , ' '`
        INDEX=0
        DEVICE_NAMES=( $DEVICE_NAMES )
        for i in $VDIS
        do
                VBD=`$XE vbd-create vm-uuid=${VM_UUID} device=${DEVICE_NAMES[$INDEX]} vdi-uuid=${i}`
                if [ $? -ne 0 ]
                then
                        echo "Failed to connect $i to ${DEVICE_NAMES[$INDEX]}"
                        exit 2
                fi
                $XE vbd-plug uuid=$VBD
                if [ $? -ne 0 ]
                then
                        echo "Failed to plug $VBD"
                        exit 3
                fi
                let INDEX++
        done
}

function detach() {
        # Here we detach the disks
        VBDS=`$XE vdi-list sr-uuid=${REMOVABLE_SR_UUID} params=vbd-uuids --minimal | tr , ' '`
        for i in $VBDS
        do
                $XE vbd-unplug uuid=${i}
                $XE vbd-destroy uuid=${i}
        done
        echo "Storage Detached from VM"
}
case "$1" in
        attach) attach
                ;;
        detach) detach
                ;;
        *)      echo "Usage: $0 [attach|detach]"
                exit 1
esac



Cheers!

Bonding + VLAN tagging + Bridge – updated

Wednesday, April 25th, 2012

In the past I hacked around a problem with the order of starting (and with several bugs) a network stack combined of network bonding (teaming) + VLAN tagging, and then with network bridging (aka – Xen bridges). This kind of setup is very useful for introducing VLAN networks to guest VMs. This works well on Xen (community, Server), however, on RHEL/Centos 5 versions, the startup scripts (ifup and ifup-eth) are buggy, and do not handle this operation correctly. It means that, depending on the update release you use, results might vary from “everything works” to “I get bridges without VLANs” to “I get VLANs without bridges”.

I have hacked a solution in the past, modifying /etc/sysconfig/network-scripts/ifup-eth and fixing some bugs in it, however, both maintaining the fix on every release of ‘initscripts’ package has proven, well, not to happen…

So, instead, I present you with a smarter solution, better adept to updates supplied from time to time by RedHat or Centos, using predefined ‘hooks’ in the ifup scripts.

Create the file /sbin/ifup-pre-local with the following contents:



#!/bin/bash
# $1 is the config file
# $2 is not interesting
# We will start the vlan bonding before any bridge

DIR=/etc/sysconfig/network-scripts

[ -z "$1" ] &amp;&amp; exit 0
. $1

if [ "${DEVICE%%[0-9]*}" == "xenbr" ]
then
    for device in $(LANG=C egrep -l "^[[:space:]]*BRIDGE=\"?${DEVICE}\"?" /etc/sysconfig/network-scripts/ifcfg-*) ; do
        /sbin/ifup $device
    done
fi

You can download this scrpit. Don’t forget to change it to be executable. It will call ifup for any parent device of xenbr* device called at. If the parent device is already up, no harm is done. If the parent device is not up, it will be brought up, and then the xenbr device can start normally.

Citrix XenServer 6.0 enable VM autostart

Monday, February 6th, 2012

Unlike previous versions, VMs do not have a visible property in the GUI allowing autostart. This has been claimed to collide with the HA function of the licensed version. While I believe there is a more elegant way of doing that (like – ignoring this property if HA is enabled), the following method can allow your free XenServer allow autostart of VMs:
xe pool-param-set uuid=UUID other-config:auto_poweron=true

xe vm-param-set uuid=UUID other-config:auto_poweron=true

Replace the relevant UUID values with the true required value. A small one-liner script to handle the 2nd part (enabling it for the VMs), which would enable autostart for ALL vms:

for i in `xe vm-list is-control-domain=false –minimal | tr , ‘  ‘`; do xe vm-param-set uuid=$i other-config:auto_poweron=true; done

Cheers

XenServer 6.0 with DRBD

Wednesday, January 18th, 2012

DRBD is a low-cost shared-SAN-like solution, which has several great benefits, among which are no single point of failure, and very low cost (local storage and network cable). Its main disadvantages are in the need to constantly monitor it, and make sure it does what’s expected. Also – in some cases – performance might be affected greatly.

If you need XenServer pool with VMs XenMotion (used to call it LiveMigration. I liked it better then…), but you cannot afford or do not want classic shared storage acting a single point of failure, DRBD could be for you. You have to understand the limitations, however.

The most important limitation is with data consistency. If you aim at using it as Active/Active, as I have, you need to make sure that under any circumstance you will not have split brain, as it will mean losing data (you will recover to an older point in time). If you aim at Active/Passive, or all your VMs will run on a single host, then the danger is lower, however – for A/A, and VMs spread across both hosts – the danger is imminent, and you should be aware of it.

This does not mean that you will have to run crying in case of split brain. It means you might be required to export/import VMs to maintain consistent data, and that you will have a very long downtime. Kinda defies the purpose of XenMotion and all…

Using the DRBD guid here, you will find an excellent solution, but not a complete one. I will describe my additions to this document.

So, first, you need to download the DRBD packages. I have re-packaged them, as they did not match XenServer with XS60E003 update. You can grub this particular tar.gz here: drbd-8.3.12-xenserver6.0-xs003.tar.gz . I did not use DRBD 8.4.1, as it has shown great instability and liked getting split-brained all the time. Don’t want it with our system, do we?

Make sure you have defined the private link between your hosts, both as a network interface, as described, and in both servers’ /etc/hosts file. It will be easier later. Verify that the host hostname matches the configuration file, else DRBD will not start.

Next, follow the mentioned guide.

Unlike this guide, I did not define DRBD to be Active/Active in the configuration file. I have noticed that upon reboot of the pool master (and always it), probably due to timing issues, as the XE Toolstack did not release the DRBD device, it would have started in split-brain mode, and I was incapable of handling it correctly. No matter when I have tried to set the service to start, as early as possible, it would have always start in split-brain mode.

The workaround was to let it start in passive mode, and while being read-only device, XE Toolstack cannot use it. Then I wait (in /etc/rc.local) for it to complete sync, and connect the PBD.

You will need each host PBD for this specific SR.

You can do it by running:

1
2
3
4
for i in `xe host-list --minimal` ; do \
echo -n "host `xe host-param-get param-name=hostname uuid=$i`  "
echo "PBD `xe pbd-list sr-uuid=$(xe  sr-list name-label=drbd-sr1 --minimal) --minimal`"
done

This will result in a line per host with the DRBD PBD uuid. Replace drbd-sr1 with your actual DRBD SR name.

You will require this info later.

My drbd.conf file looks like this:

?Download drbd.conf
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
# You can find an example in  /usr/share/doc/drbd.../drbd.conf.example

#include "drbd.d/global_common.conf";
#include "drbd.d/*.res";

resource drbd-sr1 {
protocol C;
startup {
degr-wfc-timeout 120; # 2 minutes.
outdated-wfc-timeout 2; # 2 seconds.
#become-primary-on both;
}

handlers {
    split-brain "/usr/lib/drbd/notify.sh root";
}

disk {
max-bio-bvecs 1;
no-md-flushes;
no-disk-flushes;
no-disk-barrier;
}

net {
allow-two-primaries;
cram-hmac-alg "sha1";
shared-secret "Secr3T";
after-sb-0pri discard-zero-changes;
after-sb-1pri discard-secondary;
after-sb-1pri consensus;
after-sb-2pri disconnect;
#after-sb-2pri call-pri-lost-after-sb;
max-buffers 8192;
max-epoch-size 8192;
sndbuf-size 1024k;
}

syncer {
rate 1G;
al-extents 2099;
}

on xenserver1 {
device /dev/drbd1;
disk /dev/sda3;
address 10.1.1.1:7789;
meta-disk internal;
}
on xenserver2 {
device /dev/drbd1;
disk /dev/sda3;
address 10.1.1.2:7789;
meta-disk internal;
}
}

I did not force them both to become primary, as split-brain handling in A/A mode is very complex. I have forced them to start as secondary.

Then, in /etc/rc.local, I have added the following lines:

?Download rc.local
1
2
3
4
5
6
7
echo 1 > /sys/devices/system/cpu/cpu1/online
while grep sync /proc/drbd > /dev/null 2>&1
do
        sleep 5
done
/sbin/drbdadm primary all
/opt/xensource/bin/xe pbd-plug uuid=dfb02709-2483-a11a-cb0e-eac0fb05d8e2

This performs the following:

  • Add an additional core to Domain 0, to reduce chances of CPU overload with DRBD
  • Waits for any sync to complete (if DRBD failed, it will continue, but you will have a split brain, or no DRBD at all)
  • Brings the DRBD device to primary mode. I have had only one DRBD device, but this can be performed selectively for each device
  • Reconnects the PBD which, till this point in the boot sequence, was disconnected. An important note - replace the uuid with the one discovered above for each host - each host should unplug its own PBD.

To sum it up - until sync has been completed, the PBD will not be plugged, and until then, no VMs can run on this SR. Split brain handling for A/P configuration is so much easier.

Some additional notes:

  • I have failed horribly when the interconnect cable was down. I did not implement hardware fencing mechanisms, but it would probably be a very good practice for production systems. Disconnecting the cross cable will result in a split brain.
  • For this system to be worthy, it has to have external monitoring. DRBD must be monitored at all times.
  • Practice and document cases of single node failure, both nodes failure, host master failure, etc. Make sure you know how to react before it happens in real-life.
  • Performance was measured on a Linux RHEL6 VM to be about 82MB/s. The hardware it was tested on was Dell PE R610 with a very nice RAID5 array, etc. When the 2nd host was down, performance resulted in abour 450MB/s, so the bandwidth, in this particular case, matters.
  • Performance test was done using the command:
    dd if=/dev/zero bs=1M of=/tmp/test_file.dd oflag=direct
    Without the oflag=direct, the system will overload the disk write cache of the OS, and not the disk itself (at least - not immediately).
  • I did not test random-access performance.
Hope it helps
